Admiration - Maple Canyon Exclusive Smooth - Hardwood
Description
|
Characteristics |
Mirage Classic |
|
|
Description |
• Solid prefinished hardwood flooring with tongues and grooves • Micro-V bevel (on 4 sides) |
|
|
Thickness |
3/4" |
|
|
Width |
3-1/4" |
4-1/4” |
|
Length1 |
Random lengths from 10” (250 mm) to 76” (1,930 mm) |
|
|
Installation |
Nailed or stapled down (above and on grade) |
|
|
Subfloor |
Wood |
|
|
Species |
3 species: Maple, Red Oak, White Oak |
|
|
Grade |
• Select & Better: Selection of more uniform wood grain with slight variations in natural shading. • Exclusive: Wood planks with some pronounced and nuanced coloration. The Exclusive grade offers a range of color variation. • Character: These floors are appreciated for their pronounced color variation. They feature open and closed knots, mineral streaks, cracks, surface holes, and other character or milling marks. Some distinctive marks may become prominent over time due to changes in the environment. |
|
|
Color choice |
Some products may not be available. Ask your Mirage representative or consult the Product Chart. |
|
|
Finish |
Finishing system made of aluminum oxide and nanosilica particle composites suspended in UV cured polyurethane. • DuraMatt® (5% gloss) • Nanolinx® HD • Cashmere®* (18% gloss) • Nanolinx® Commercial (18% gloss) |
|
|
UV Protection: All products |
||
|
Static Friction Coefficient (ASTM-D-2047): Slippery resistance superior to 0.5 |
||
|
Applicable standards |
Surface Burning (ASTM-E-84): • FSI (Flame Spread Index) 100 to 150 Class C (depends on wood species) • SD (Smoke Development) 75 to 400 (depends on wood species) |
Surface Burning (ULC-S-102-2): • FSV (Flame Spread Value) 100 to 150 (depends on wood species) • SD (Smoke Development) 200 to 300 (depends on wood species) |
|
Critical radiant flux (ASTM-E-648-94a): 0.25 to 0.40 watt/cm2 (depends on wood species) |
R value: R 0.6 to 0.8 (depends on wood species) |
|
|
Formaldehyde and VOC emissions (CDPH 1.2, 2017) : Target product group (Classic) conform |
||
|
Provenance |
Made in St-Georges, Qc, Canada. |
|
|
Use |
Residential, light commercial or commercial (Nanolinx® Commercial) |
|
|
Accessory |
Round Stair nosing, Square Stair nosing, Round Reducer, Threshold, ”T” molding, Quarter round |
|
|
Warranty |
• Structural lifetime limited warranty (Relative humidity must always be maintained within a range of 35% and 55%). |
• 35-year finish warranty for residential applications • 3-year finish warranty for light commercial applications • 5-year finish warranty for commercial applications with Nanolinx® Commercial |
|
Packaging |
3-1/4” |
4-1/4” |
|
Content of a box Size of a box Weight of a box Content of a pallet Size of a pallet |
• 20 sq. ft. • 79” L x 10-1/2” W x 3-1/4” H • 49 to 60 lbs • 48 boxes = 960 sq. ft. (4 boxes/W x 12 boxes/H) • 79” L x 42” W x 42” H |
• 18 sq. ft. • 85-1/2” L x 9” W x 3-1/4” H • 45 to 55 lbs • 48 boxes = 864 sq. ft. (4 boxes/W x 12 boxes/H) • 85-1/2” L x 37” W x 42” H |
|
Relative species hardness |
|
|
|
NWFA Janka Test Hardness test (ASTM-D-143)
Red Oak 1290 lbs* - 100% *lbs = Applied force in pounds |
• Red Oak 1,290 lbs - average hardness • White Oak 1,360 lbs - 5% harder • Maple 1,450 lbs - 12% harder |
|
